WG60A(0-1000GU)

Gloss Meter WG60A Function Description

(1)One button to complete measurement: one operation can complete measurement; Measuring light incident angle meet ISO 2813 three measuring light incident angle.

(2) Manually entering standard samples gloss data;

(3) Humanized design, good man-machine communication interface;

(4) Single angle can store 10000 testing records, storage structure is: 100 prototypes, each prototype with 100 testing data;

(6) Data browsing and viewing function;

(7) The machine has automatic shutdown function, low power warning functions, full data storage hint functions;

(8) USB communication interface to communicate with PC;

(9) PC software can be extended more functions.



Attachment Description

(1) Power adapter: standard + 5V, 2A external power supply;

(2) Standard board: provide calibration criterion.

(3) USB cable: connect instrument to PC.



Specification	Unit	Single Gloss Meter
Measuring Angle	degree	60°
Measuring Range	GU	60°: 0-1000
Measuring Spot	mm	60°: 9x15
Division Value	GU	0-1000: 0.1
Repeatability	GU	0-100:0.2 >100:0.2%
Indication Error	GU	±1.5
Zero Error	GU	0.2
Working Temperature	℃	10℃ - 40℃
Storage Temperature	℃	-10℃ - 70℃
Humidity Range		Relative humidity less than 85%,without condensation
Power Adapter		Section 2 5alkaline batteries/power adapter
Volume	mm	159x49x72
Weight	g	500
