WG60G(for arc cambered surface)

  • 1. Test small parts, cambered, arc surface.
    2. Apply on paint, ink, stoving varnish, coating, wood products; Marble, granite, vitrified polished tile, pottery brick and porcelain; Plastic, printing, paper; Other metallic material;
    3. Include software to connect PC
    Product description: This gloss meter is designed and manufactured with the reference to the international standardISO-2813、ASTM-C584、ASTM-D523、DIN-67530、ASTM-D2457、JND-A60、JND-P60.
  • 留言咨询
Product Name Gloss meter
Model WG60G
Measurement Range 0-2000Gu
Application Metal, plating, glass mirror and high gloss surface.
Instrument Dimensions 122x34x60mm
Projection Angle 60°
Measuring Spot (ellipse: long axis*minor axis)3mm*1mm
Calibration Mode Manual calibration/bring up the stored data to calibration/manually set the tolerance
Measuring Mode Automatic measurement/ manual measurement/single measurement/average measurement and cross measurement for a variety of combination measuring mode
Data Storage 500 groups  Set standard sample in any stored data, user define the tolerance range
Language Chinese/English
Output Connect the micro printer to realize real-time output of measured data
Division Value 0.1Gu
Repeatability 0.2Gu
Reproducibility 0.4Gu
Indication Error 1.0Gu
International Standard 60° ISO-2813、ASTM-C584、ASTM-D523、DIN-67530、ASTM-D2457、JND-A60、JND-P60
National Standard 60° GB 9754、GB 9966、GB 8807
Standard Accessories Power adapter/user manual/warranty certification/standard board
Optional Accessories Micro-printer
